Grommet - Brake Pipe Support

Grommet - Brake Pipe Support

0.31

Application: Series 1 1954 to 1958, Series 2 and Series 3.
Description: Grommet to support brake pipe on rear axle casing. Used with clip 56666.
Approximate dimensions: overall length 21.5mm(0.85"), inside diameter 7mm(0.3"), outside diameter 14.5mm(0.6")
find out more

Clip for brake pipe grommet

Clip for brake pipe grommet

0.61

Application: Series 1 1954 to 1958, Series 2 and Series 3.
Description: Clip for brake pipe support grommet 6860L. Used on rear axle casing on all Series models from 1954 to 1984.
Approximate dimensions: 11mm(7/16") wide, 34mm(1.3") long, mounting hole 5mm(0.2") diameter, internal diameter of clip when closed 13mm.
find out more

Sealing Ring Water Pump to Cylinder Head

Sealing Ring Water Pump to Cylinder Head

2.18

Application: Series 1 1.6ltr & 2.0Ltr and Series 2A/3 2.6ltr petrol engines.
Description: Thick rubber sealing ring between water pump and cylinder head.
Approximate dimensions: internal diameter 13mm (1/2"), outside diameter 24mm (0.95"), thickness 5.3mm (0.2")
find out more

Gasket Set for Series Gearboxes

Gasket Set for Series Gearboxes

4.20

Application: Series 1, Series 2 & 3 with 4 or 6 cylinder engines.
Description: Set of replacement gaskets for main and transfer gearboxes. Does NOT include seals.
find out more

Water Pump Series1 Petrol

Water Pump Series1 Petrol

51.00

Application: Series 1 1.6ltr & 2.0ltr petrol (gasolene) engines.

Description: Reproduction cast iron water pump, supplied with gaskets.
find out more

Gaiter for High/Low Gear Lever

Gaiter for High/Low Gear Lever

2.46

Application: Series 1, Series 2/2A and Series 3.

Description: Reproduction rubber gaiter for the high/low gear lever.

Approximate dimensions: Overall length 143mm, height 90mm.

find out more

Oil Seal Set for Gearbox

Oil Seal Set for Gearbox

13.70

Application: Series 1, 2 & 3 with 4 or 6 cylinder engine.
Description: Set of oil seals and 'O' rings for main and transfer gearboxes. Includes seals for selector shafts.
find out more

Copper Ring Water Pump to Thermostat Housing

Copper Ring Water Pump to Thermostat Housing

7.44

Application: Series One with 1.6 or 2 litre petrol engine. Series Two with 2 litre petrol engine.
Description: Copper ring to support 'O' ring between water pump and thermostat housing.
Approximate dimensions: outside diameter 16mm(0.63"), inside diameter 11mm(0.43"), height 7.5mm(0.3")
find out more

Wheel Stud for Series 1

Wheel Stud for Series 1

5.82

Application: All Series One models.

Description: Reproduction wheel stud for Series 1. Threaded 9/16"BSF. Use with nut 217361.

Approximate dimensions: Overall length 52mm(2"), short threaded end 12mm(0.47"), long threaded end 27.5mm(1.08"), land 12.5mm(0.5")

find out more

These Superb Prices are ONLY available when you order ON-LINE

Digital Dispensary > LAND Rover Series One Parts > Land Rover Series One Engine Parts
Page:  1  2  3  4  5  ...   >   >>
Sump Gasket Series 1 Ref: 267780
Application: Series 1 1600cc or 2000cc petrol (gasolene) engine.
Description: Original cork sump gasket, manufactured in the 1950's.

Price: 9.02 (10.82 Including VAT at 20%)




People who bought this item also bought:
1. Yellow Knob - 4WD Gear lever (Ref: 232813)
2. Gasket By-pass Hose Ends (Ref: 210419)
3. Rotor Arm (Ref: 261242)
Sump Gasket Series 1
Gasket, Cylinder Head 1.6 litre Petrol Ref: 212322
Application: Series 1 1600cc from 1948 to 1951.

Description: Reproduction copper composite cylinder head gasket.

Price: 58.00 (69.60 Including VAT at 20%)



Gasket, Cylinder Head 1.6 litre Petrol
Gasket, Cylinder Head 2.0 litre Petrol Ref: 231046
Application: Series 1 2.0 litre petrol 1954, this the early engine with siamese bores.

Description: Copper composite cylinder head gasket. This is for the early engines with very little spacing between cylinders 1 & 2 and between cylinders 3 & 4.

Price: 58.00 (69.60 Including VAT at 20%)



Gasket, Cylinder Head 2.0 litre Petrol
Gasket, Cylinder Head 2.0 litre Petrol Ref: 269476
Application: Series 1 2.0 litre petrol 1955 onwards. Series 2 2.0litre petrol.
Description: New reproduction copper composite cylinder head gasket.

Price: 58.00 (69.60 Including VAT at 20%)




People who bought this item also bought:
1. Head Gasket Set 1600cc (Ref: ZZCB310)
2. Sealing Ring Water Pump to Cylinder Head (Ref: RTC1975)
3. Copper Ring Water Pump to Thermostat Housing (Ref: 9197)
Gasket, Cylinder Head 2.0 litre Petrol
Head Gasket Set 1600cc Ref: ZZCB310
Application: Series 1 with 1.6litre petrol engine.
Description: Set of gaskets for cylinder head overhaul of 1600cc petrol engine.

Price: 87.00 (104.40 Including VAT at 20%)




People who bought this item also bought:
1. Oil Seal Set for Gearbox (Ref: 600603KIT)
2. Water Pump Series1 Petrol (Ref: 269974)
3. Gasket Set for Series Gearboxes (Ref: 600603D)
Head Gasket Set 1600cc
Set of Big End Bearings 2ltr Series1, 0.010" Ref: 523302SET
Application: Series1 2000cc petrol engine.

Description: Engine set of Big End bearing shells (connecting rod to crankshaft), 0.010" undersize (first regrind). These are for the later 2 litre engine, 1954-1958. Shell width 7/8"(22.3mm).

Price: 188.50 (226.20 Including VAT at 20%)



Set of Big End Bearings 2ltr Series1, 0.010
Set of 4 Pistons for 2.0 Litre Petrol Engine Ref: S1PISTONSET
Application: Series 1 engine with 2.0 litre petrol engine.
Description: Reproduction set of 4 pistons with piston rings, gudgeon pins and circlips. Available in standard, .020", 0.030", 0.040" and 0.060" oversize.

Price: 625.00 (750.00 Including VAT at 20%)

Size:
Standard
0.020" oversize
0.030" oversize
0.040" oversize
0.060" oversize


Set of 4 Pistons for 2.0 Litre Petrol Engine
Exhaust Valve 1600cc Ref: 234993
Application: Series 1 1.6 litre petrol engines.

Description: Exhast valve.

Approximate dimensions: overall length 119mm(4.68"), head diameter 32mm(1.3"), stem diameter 8.8mm(0.35")

Price: 8.50 (10.20 Including VAT at 20%)




People who bought this item also bought:
1. Copper Washer Oil Feed Pipe (Ref: 232039)
2. Water Outlet (Ref: 263607D)
3. Rotor Arm (Ref: 261242)
Exhaust Valve 1600cc
Exhaust Valve 2000cc Ref: 264137
Application: Series 1 two litre petrol engines.

Description: Reproduction exhast valve.

Approximate dimensions: overall length 116.5mm(4.6"), head diameter 32mm(1.3"), stem diameter 8.8mm(0.35")

Previous part number: 234994

Price: 29.00 (34.80 Including VAT at 20%)




People who bought this item also bought:
1. Sump Gasket Series 1 (Ref: 267780)
2. Inlet Valve (Ref: 233427)
Exhaust Valve 2000cc
Inlet Valve Ref: 233427
Application: Series 1 with either 1600cc or 2000cc petrol(gasolene) engine.

Description: Reproduction inlet valve.

Approximate dimensions: Overall length 120mm(4.7"), head diameter 43mm(1.7"), stem diameter 8.7mm(0.34")

Price: 27.90 (33.48 Including VAT at 20%)




People who bought this item also bought:
1. Yellow Knob - 4WD Gear lever (Ref: 232813)
2. Gasket By-pass Hose Ends (Ref: 210419)
3. Water Outlet (Ref: 263607D)
Inlet Valve
Digital Dispensary > LAND Rover Series One Parts > Land Rover Series One Engine Parts
Page:  1  2  3  4  5  ...   >   >>

Haven't found what you want? Then try our quotation service.

Main Pages


New Products

Steering Arm - Series 1

Steering Arm - Series 1

17.82

Application: Series 1 models 1948 to 1956 approx.

Description: Drop arm for early type steering box. This arm is held in place with a pinch bolt.

Approximate dimensions: Overall length 17.4cm(6.9")

find out more

'D' Washer - Pedal Shaft

'D' Washer - Pedal Shaft

0.96

Application: Series 1 models.

Description: 'D' washer for support shaft for brake and clutch pedals.

Approximate dimensions: Outside diameter 38mm(1.5"), thickness 3mm(1/8").


find out more

Fixing Kit for Manifolds - Metric

Fixing Kit for Manifolds - Metric

12.83

Application: Series 3 from 1980 with 2.25 litre petrol engine.

Description: Metric threaded kit of fixings to hold manifolds to cylinder head. Kit includes 6 bolts, 2 set screws, 3 studs, 9 plain washers, 11 lock washers, 3 nuts, 2 clamps and 2 lockers

find out more

Fixing Kit for Manifolds - Imperial

Fixing Kit for Manifolds - Imperial

10.20

Application: Series 2 and Series 3 to approx 1980 with 2.25 litre petrol engine.

Description: Imperial (inch) threaded kit of fixings to hold manifolds to cylinder head. Kit includes 6 bolts, 2 set screws, 3 studs, 9 plain washers, 11 lock washers, 3 nuts, 2 clamps and 2 lockers

find out more

Shackle Plate Rear

Shackle Plate Rear

11.16

Application: Series1 1948 to 1953.

Description: Shackle plate for rear springs with plain 9/16" diameter holes.

Approximate dimensions: Length 113mm(4.45"), width 38mm(1.5"), thickness 9.2mm(0.36")
find out more

Shackle Plate Rear

Shackle Plate Rear

13.02

Application: Series 1 1948 to 1953.

Description: Shackle plate for rear springs with 1/2"BSF threaded holes.

Approximate dimensions: Length 113mm(4.45"), width 38mm(1.5"), thickness 9.2mm(0.36")

find out more

Clip for 3/16" Brake Pipe

Clip for 3/16

1.39

Application: Series1, Series2/2A and Series3 models.

Description: Reproduction stainless steel clip for brake pipes. Intended for 3/16" pipe, but will work with 1/4" diameter pipe also.

Approximate dimensions: Length 20mm(0.8"), width 10mm(3/8"), height 5mm(0.2"), hole diameter 4mm(0.16").

find out more

Rear End-plate for Cylinder Head

Rear End-plate for Cylinder Head

97.66

Application: Series 1 petrol models 1948 to 1958, Series 2 models with 2 litre petrol engine.

Description: Reproduction end plate in cast aluminium with mounting aperature for thermo switch.

Approximate dimensions: Length 91mm(3.6"), height 84mm(3.3"), depth 18.4mm(0.72")

find out more
