Grommet - Brake Pipe Support

Grommet - Brake Pipe Support

0.31

Application: Series 1 1954 to 1958, Series 2 and Series 3.
Description: Grommet to support brake pipe on rear axle casing. Used with clip 56666.
Approximate dimensions: overall length 21.5mm(0.85"), inside diameter 7mm(0.3"), outside diameter 14.5mm(0.6")
find out more

Clip for brake pipe grommet

Clip for brake pipe grommet

0.61

Application: Series 1 1954 to 1958, Series 2 and Series 3.
Description: Clip for brake pipe support grommet 6860L. Used on rear axle casing on all Series models from 1954 to 1984.
Approximate dimensions: 11mm(7/16") wide, 34mm(1.3") long, mounting hole 5mm(0.2") diameter, internal diameter of clip when closed 13mm.
find out more

Sealing Ring Water Pump to Cylinder Head

Sealing Ring Water Pump to Cylinder Head

2.18

Application: Series 1 1.6ltr & 2.0Ltr and Series 2A/3 2.6ltr petrol engines.
Description: Thick rubber sealing ring between water pump and cylinder head.
Approximate dimensions: internal diameter 13mm (1/2"), outside diameter 24mm (0.95"), thickness 5.3mm (0.2")
find out more

Gasket Set for Series Gearboxes

Gasket Set for Series Gearboxes

4.20

Application: Series 1, Series 2 & 3 with 4 or 6 cylinder engines.
Description: Set of replacement gaskets for main and transfer gearboxes. Does NOT include seals.
find out more

Water Pump Series1 Petrol

Water Pump Series1 Petrol

51.00

Application: Series 1 1.6ltr & 2.0ltr petrol (gasolene) engines.

Description: Reproduction cast iron water pump, supplied with gaskets.
find out more

Gaiter for High/Low Gear Lever

Gaiter for High/Low Gear Lever

2.46

Application: Series 1, Series 2/2A and Series 3.

Description: Reproduction rubber gaiter for the high/low gear lever.

Approximate dimensions: Overall length 143mm, height 90mm.

find out more

Oil Seal Set for Gearbox

Oil Seal Set for Gearbox

13.70

Application: Series 1, 2 & 3 with 4 or 6 cylinder engine.
Description: Set of oil seals and 'O' rings for main and transfer gearboxes. Includes seals for selector shafts.
find out more

Copper Ring Water Pump to Thermostat Housing

Copper Ring Water Pump to Thermostat Housing

7.44

Application: Series One with 1.6 or 2 litre petrol engine. Series Two with 2 litre petrol engine.
Description: Copper ring to support 'O' ring between water pump and thermostat housing.
Approximate dimensions: outside diameter 16mm(0.63"), inside diameter 11mm(0.43"), height 7.5mm(0.3")
find out more

Wheel Stud for Series 1

Wheel Stud for Series 1

5.82

Application: All Series One models.

Description: Reproduction wheel stud for Series 1. Threaded 9/16"BSF. Use with nut 217361.

Approximate dimensions: Overall length 52mm(2"), short threaded end 12mm(0.47"), long threaded end 27.5mm(1.08"), land 12.5mm(0.5")

find out more

These Superb Prices are ONLY available when you order ON-LINE

Digital Dispensary > LAND Rover Series One Parts > Land Rover Series One Suspension Parts
Page:  1  2  3   >   >>
Spring Bush for 2.5" wide Springs Ref: 548205
Application Series 1, 2 & 3.
Description: Original 'Clayflex' spring bushes. Suitable for all 2.5"(63.5mm) wide springs.
Approximate dimensions: overall length 70mm (2.75"), inside diameter 9/16"(14.3mm). outside diameter 30.2mm(1 3/16")

Price: 2.17 (2.60 Including VAT at 20%)




People who bought this item also bought:
1. Replacement Suspension Bush (Ref: 569746D)
2. Bush for Shock Absorber (Ref: 552819)
3. Washer - Shock Absorber Fixing (Ref: 243022A)
Spring Bush for 2.5
Repacement Spring Bush for 2.5" wide Springs Ref: 548205D
Application Series 1, 2 & 3.
Description: Replacement spring bushes. Suitable for all 2.5"(63.5mm) wide springs.
Approximate dimensions: overall length 70mm (2.75"), inside diameter 9/16"(14.3mm). outside diameter 30.2mm(1 3/16")

Price: 0.80 (0.96 Including VAT at 20%)



Repacement Spring Bush for 2.5
Bush for Narrow Springs Ref: 230713
Application: Series 1 1948 to 1953.

Description: Reproduction spring eye bush for narrow springs.

Approximate dimensions: Overall length 2"(51mm), outer sleeve length 1.75"(44.5mm), outside diameter 1 3/16"(30.2mm), inside diameter 9/16"(14.3mm)

Price: 7.46 (8.95 Including VAT at 20%)



Bush for Narrow Springs
Shackle Pin Ref: 233625
Application: Series 1 1954 to 1958, Series 2 to suffix A.
Description: Shackle pin for rear of front springs. This is the shouldered type pin with 9/16" diameter shank and 1/2" diameter threaded end.
Approximate dimensions: Overall length (less head) 130mm(5.12"), shouldered portion 9/16" diameter by 92mm(3.62"), thread is 1.2"BSF.

Price: 18.13 (21.76 Including VAT at 20%)




People who bought this item also bought:
1. Seal Kit for Brake Master Cylinder (Ref: ZZSP1975-5)
2. Rear Shock Absorber (Ref: RTC4232D)
3. Axle Set of Brake Shoes - 10" (Ref: STC2796DKIT)
Shackle Pin
Shackle Pin Ref: 210699
Application: Series 1 1948 to 1953.

Description: Reproduction shackle pin for rear of rear springs where the narrow 1.75" springs are fitted.

Approximate dimensions: Overall length 3.75", shank diameter 9/16", thread 1/2"BSF.

Price: 11.60 (13.92 Including VAT at 20%)



Shackle Pin
Shackle Pin Ref: 236969
Application: Series 1 1954 to 1958, Series 2 to suffix A.
Description: Shackle pin for rear of rear springs. This is the shouldered type pin with 9/16" diameter shank and 1/2" diameter threaded end.
Approximate dimensions: Overall length (less head) 108mm(4.25"), shouldered portion 9/16" diameter by 70mm(2.75"), thread is 1.2"BSF.

Price: 1.20 (1.44 Including VAT at 20%)



Shackle Pin
Shackle Pin Ref: 270741A
Application: Series 1 1954 to 1958 and Series 2 1958 to 1960.

Description: Shackle pin for front of front spring.

Approximate dimensions: Overall length(excluding head) 112mm (4.4"), shank 5/8"diameter(15.9mm), threaded portion 9/16"BSF by 24mm(0.95") long.

Price: 13.95 (16.74 Including VAT at 20%)




People who bought this item also bought:
1. Seal Kit for Brake Master Cylinder (Ref: ZZSP1975-5)
2. Axle Set of Brake Shoes - 10" (Ref: STC2796DKIT)
3. Rear Shock Absorber (Ref: RTC4232D)
Shackle Pin
Shackle Plate Rear Ref: 58192
Application: Series 1 1948 to 1953.

Description: Shackle plate for rear springs with 1/2"BSF threaded holes.

Approximate dimensions: Length 113mm(4.45"), width 38mm(1.5"), thickness 9.2mm(0.36")

Price: 10.85 (13.02 Including VAT at 20%)




People who bought this item also bought:
1. GKN boxed Universal Joint Repair Kit (Ref: TVC100010D)
2. Washer Shock Absorber Bush (Ref: RYF500160)
3. Bush for Shock Absorber (Ref: 552819D)
Shackle Plate Rear
Shackle Plate Rear Ref: 210691
Application: Series1 1948 to 1953.

Description: Shackle plate for rear springs with plain 9/16" diameter holes.

Approximate dimensions: Length 113mm(4.45"), width 38mm(1.5"), thickness 9.2mm(0.36")

Price: 9.30 (11.16 Including VAT at 20%)




People who bought this item also bought:
1. GKN boxed Universal Joint Repair Kit (Ref: TVC100010D)
2. Washer Shock Absorber Bush (Ref: RYF500160)
3. Shackle Plate Rear (Ref: 58192)
Shackle Plate Rear
Spring Dowel Bolt Ref: 243129
Application: Series 1 1954-1958, Series 2 and Series 3 front springs.

Description: Centre bolt of front spring. Holds spring together and locates spring on axle.

Approximate dimensions: 5/16" BSF thread, spindle is 1 15/16" long (49mm), head is 1/2"(12.5mm) diameter and 3/8" (9.5mm) long.

Price: 4.26 (5.11 Including VAT at 20%)




People who bought this item also bought:
1. 'O' Ring for Thermostat (Ref: 527235)
2. Gasket Exhaust Manifold to Down Pipe (Ref: 213358)
3. Gasket Cylinder Head End Plates (Ref: 213811)
Spring Dowel Bolt
Digital Dispensary > LAND Rover Series One Parts > Land Rover Series One Suspension Parts
Page:  1  2  3   >   >>

Haven't found what you want? Then try our quotation service.

Main Pages


New Products

Steering Arm - Series 1

Steering Arm - Series 1

17.82

Application: Series 1 models 1948 to 1956 approx.

Description: Drop arm for early type steering box. This arm is held in place with a pinch bolt.

Approximate dimensions: Overall length 17.4cm(6.9")

find out more

'D' Washer - Pedal Shaft

'D' Washer - Pedal Shaft

0.96

Application: Series 1 models.

Description: 'D' washer for support shaft for brake and clutch pedals.

Approximate dimensions: Outside diameter 38mm(1.5"), thickness 3mm(1/8").


find out more

Fixing Kit for Manifolds - Metric

Fixing Kit for Manifolds - Metric

12.83

Application: Series 3 from 1980 with 2.25 litre petrol engine.

Description: Metric threaded kit of fixings to hold manifolds to cylinder head. Kit includes 6 bolts, 2 set screws, 3 studs, 9 plain washers, 11 lock washers, 3 nuts, 2 clamps and 2 lockers

find out more

Fixing Kit for Manifolds - Imperial

Fixing Kit for Manifolds - Imperial

10.20

Application: Series 2 and Series 3 to approx 1980 with 2.25 litre petrol engine.

Description: Imperial (inch) threaded kit of fixings to hold manifolds to cylinder head. Kit includes 6 bolts, 2 set screws, 3 studs, 9 plain washers, 11 lock washers, 3 nuts, 2 clamps and 2 lockers

find out more

Shackle Plate Rear

Shackle Plate Rear

11.16

Application: Series1 1948 to 1953.

Description: Shackle plate for rear springs with plain 9/16" diameter holes.

Approximate dimensions: Length 113mm(4.45"), width 38mm(1.5"), thickness 9.2mm(0.36")
find out more

Shackle Plate Rear

Shackle Plate Rear

13.02

Application: Series 1 1948 to 1953.

Description: Shackle plate for rear springs with 1/2"BSF threaded holes.

Approximate dimensions: Length 113mm(4.45"), width 38mm(1.5"), thickness 9.2mm(0.36")

find out more

Clip for 3/16" Brake Pipe

Clip for 3/16

1.39

Application: Series1, Series2/2A and Series3 models.

Description: Reproduction stainless steel clip for brake pipes. Intended for 3/16" pipe, but will work with 1/4" diameter pipe also.

Approximate dimensions: Length 20mm(0.8"), width 10mm(3/8"), height 5mm(0.2"), hole diameter 4mm(0.16").

find out more

Rear End-plate for Cylinder Head

Rear End-plate for Cylinder Head

97.66

Application: Series 1 petrol models 1948 to 1958, Series 2 models with 2 litre petrol engine.

Description: Reproduction end plate in cast aluminium with mounting aperature for thermo switch.

Approximate dimensions: Length 91mm(3.6"), height 84mm(3.3"), depth 18.4mm(0.72")

find out more
