Brass Nut 5/16"BSF

Brass Nut 5/16

1.66

Application: Series1 exhaust manifold.

Description: Brass nut 5/16"BSF for holding downpipe to exhaust manifold.

Approximate dimensions: 3/8"(9.5mm) high, 17/32"(13.5mm) across flats.

find out more

Grommet - Brake Pipe Support

Grommet - Brake Pipe Support

0.31

Application: Series 1 1954 to 1958, Series 2 and Series 3.
Description: Grommet to support brake pipe on rear axle casing. Used with clip 56666.
Approximate dimensions: overall length 21.5mm(0.85"), inside diameter 7mm(0.3"), outside diameter 14.5mm(0.6")
find out more

Clip for brake pipe grommet

Clip for brake pipe grommet

0.61

Application: Series 1 1954 to 1958, Series 2 and Series 3.
Description: Clip for brake pipe support grommet 6860L. Used on rear axle casing on all Series models from 1954 to 1984.
Approximate dimensions: 11mm(7/16") wide, 34mm(1.3") long, mounting hole 5mm(0.2") diameter, internal diameter of clip when closed 13mm.
find out more

Ignition Coil

Ignition Coil

30.11

Application: Series 1 and Series 2.
Description: Reproduction ignition coil with screw in high tension connection. Supplied with acorn nut and split washer.
Approximate dimensions: Body diameter 54.8mm(2.2"), height 15cm(5.9")
find out more

Stud for Exhaust Manifold

Stud for Exhaust Manifold

1.85

Application: Series 1 1.6 and 2.0 litre, Series 2 2 litre.

Description: Stud to hold downpipe to exhaust manifold.

Approximate dimesions: 5/16"BSF threads to both ends, overall length 1.25"(32mm)

find out more

Black High Tension Lead, Copper Cored

Black High Tension Lead, Copper Cored

1.86

Application: Series One and Series Two
Description: Black high tension cable for spark plugs. 7mm(0.28") outside diameter with 19 strand copper core.

Sold by the metre
find out more

Rocker Cover Gasket

Rocker Cover Gasket

7.72

Application: 1.6ltr and 2.0ltr petrol (gasolene) engines.

Description: Gasket for rocker cover to cylinder head.
find out more

Gasket Exhaust Manifold to Down Pipe

Gasket Exhaust Manifold to Down Pipe

0.96

Application: Series 1, 2 & 3 four cylinder engines.
Description: Square flange gasket for exhaust. Used on various exhaust manifolds and on some pipe to pipe exhaust joints.
find out more

Sealing Ring Water Pump to Cylinder Head

Sealing Ring Water Pump to Cylinder Head

2.18

Application: Series 1 1.6ltr & 2.0Ltr and Series 2A/3 2.6ltr petrol engines.
Description: Thick rubber sealing ring between water pump and cylinder head.
Approximate dimensions: internal diameter 13mm (1/2"), outside diameter 24mm (0.95"), thickness 5.3mm (0.2")
find out more

These Superb Prices are ONLY available when you order ON-LINE

Digital Dispensary > BOOKS and Publications > Range Rover Classic
Workshop manual 1970 to 1985 Ref: AKM 3630
Range Rover Repair Operation Manual 1970-1985
Official Land Rover manual reprinted by Brookland Books
Full repair manual covering all areas including supplement for 5 speed manual gearbox and auto box. Also gives full specifications, maintenance schedules, lubrication charts, wiring diagrams etc.
Soft back 8.5" x 11.5", 508 Pages
Models covered Range Rover 1970-1985

Price: 35.95



Workshop manual 1970 to 1985
Workshop manual 1986 to 1989 Ref: SRR660ENWM
Range Rover Workshop Manual all Petrol and diesel models from 1986 to 1989
Official Land Rover manual reprinted by Brookland Books
Covering both the 3.5 V8 petrol engined versions and the VM 2.4 diesel engined versions of the Range Rover Classic from 1986 (when the 1st EFi was introduced) upto 1989.
Soft back 8.25" x 11.5", 1030 Pages approx.
Models covered Range Rover 1986 to 1989

Price: 53.95



Workshop manual 1986 to 1989
Workshop manual 1990 to 1994 Ref: LHAWMENA
Range Rover Workshop Manual for all Petrol and diesel Models from 1990 to 1994
Official Land Rover manual reprinted by Brookland Books
Covers all Range Rover models from 1990 to 1994 including 3.9V8 petrol, 4.2V8 petrol, 2.5VM diesel and 200Tdi.
Soft back 8.25" x 11.5", 1200 Pages approx.
Models covered Range Rover Classic 1990 to 1994

Price: 53.95



Workshop manual 1990 to 1994
Haynes manual Range Rover Classic 1970 to 1994 Ref: ZZHAYNES606
RANGE ROVER CLASSIC 1970 to 1994 8-cyl Petrol Haynes Service and Repair Manual by P. Methuen and I.M. Coomber
Following the standard Haynes format, this a good workshop manual for the novice. 15 chapters plus 7 reference sections and index.
Hard back 8.4" x 10.9", 336 Pages.
Models covered: Range Rover Classic 1970 to 1994

Price: 17.80



Haynes manual Range Rover Classic 1970 to 1994
Parts Catalogue 1970 to 1985 Ref: RTC9846CH
Parts Catalogue Range Rover covering vehicles to Oct 1985 up to and including chassis suffix BA, by Land Rover Parts Ltd. Reprinted by Brooklands Books
The parts book is an absolute must for anyone embarking on a rebuild or major repair. The exploded diagrams alone more than justify it's purchase.
There is a group index and serial number information at the front and numerical index at the rear. This catalogue covers all official variations from 1970 to 10/85 including the Monteverdi 4 door. Much optional equipment and accessories are also listed.
Soft back 8.3" x 11.5", 440 pages approx.
Models covered: Range Rover to 10/85.


Price: 34.25



Parts Catalogue 1970 to 1985
Parts Catalogue Range Rover 1992 to 1995 Ref: RTC9961CB
Application: Range Rover Classic from 1992 to 1995. Covering the following engines - 3.9V8, 4.2V8, 2.5VM, 200TDi and 300TDi.

Description: Reprint by Brookland Books with 484 pages.

Approximate dimensions: 297mm(11.7") tall, 210mm(8.3") wide and 26mm(1") thick.

Price: 43.38



Parts Catalogue Range Rover 1992 to 1995
Parts Catalogue Range Rover 1986 to 1991 Ref: RTC9908CB
Parts Catalogue Range Rover Classic covering vehicles from November 1985 to end of 1991 model year. From chassis suffix CA to HA, by Land Rover Parts Ltd. Reprinted by Brooklands Books
The parts book is an absolute must for anyone embarking on a rebuild or major repair. The exploded diagrams alone more than justify it's purchase.
There is a group index and serial number information at the front and numerical index at the rear. This catalogue covers all official variations from 1985 to 1991.

Soft back 292mm(11.5") x 210mm(8.3") x 21mm(0.8"), 360 pages approx.


Price: 33.73



Parts Catalogue Range Rover 1986 to 1991
Parts Catalogue 1970 to 1985 Ref: RTC9846CH
Parts Catalogue Range Rover covering vehicles to Oct 1985 up to and including chassis suffix BA, by Land Rover Parts Ltd. Reprinted by Brooklands Books
The parts book is an absolute must for anyone embarking on a rebuild or major repair. The exploded diagrams alone more than justify it's purchase.
There is a group index and serial number information at the front and numerical index at the rear. This catalogue covers all official variations from 1970 to 10/85 including the Monteverdi 4 door. Much optional equipment and accessories are also listed.
Soft back 8.3" x 11.5", 440 pages approx.
Models covered: Range Rover to 10/85.


Price: 34.25



Parts Catalogue 1970 to 1985
Owners Handbook Range Rover 1981-82 Ref: AKM8139=
Original handbook for the introduction of the first 4 door Range Rovers from the Factory. Also covers 2 door models and the first Automatics.
Broken down into 10 sections including routine maintenance and wiring diagrams.
Soft covers 8.1" x 5.6", 186 pages.

Price: 7.95



Owners Handbook Range Rover 1981-82
Digital Dispensary > BOOKS and Publications > Range Rover Classic

Haven't found what you want? Then try our quotation service.

Main Pages


New Products

Lever Arm for 4WD Select

Lever Arm for 4WD Select

15.80

Application: Series 1 to 1955.

Description: Lever arm with bronze bush to middle hole for selection of four wheel drive in high ratio.

Approximate dimensions: Overall length 116mm(4.6"), width 15.5mm(0.61"), thickness 6mm(0.24"), distance from centre of bushed hole to centre of slotted hole 36mm(1.42"), distance from centre of bushed hole to other hole is 68mm(2.67")

find out more

Olive for Vacuum Pipe

Olive for Vacuum Pipe

0.84

Application: Series 1 and Series2 with Solex 32PBI carburettor.

Description: Brass olive for use with 1/8" copper pipe.

Approximate dimensions: Length 4.7mm(0.19"), outside diameter 4.7mm(0.19"), internal dimater 1/8"(3.2mm).

find out more

Male Union for Vacuum Pipe

Male Union for Vacuum Pipe

2.40

Application: Series 1 and Series 2A.

Description: Brass male union for 1/8" copper pipe. Threaded to fit Solex 32PBI.

Aproximate dimensions: Length 10mm(0.39"), internal diameter 1/8"(3.2mm), hex 9mm(0.35") across flats, thread 1/4"BSF.

find out more

Grommet for vacuum pipe

Grommet for vacuum pipe

3.83

Application: Series 1 and Series 2A.

Description: Split rubber grommet for us with 214228 retaining clip. Used on 1/8" diameter copper vacuum pipe.

Approximate dimensions: Length 17mm(0.67"), internal diameter 3mm(1/8"), overall diameter 9mm(0.35")

find out more

Retaining Clip for Vacuum Pipe

Retaining Clip for Vacuum Pipe

2.78

Application: Series 1 and Series 2A.

Description: Retaining clip for copper vacuum pipe for advance and retard.

Approximate dimensions: 41.5mm(1.6") x 13mm(0.5") x 9mm(0.35"). Mounting hole 7mm(0.28")

find out more

Installer Oil Seal

Installer Oil Seal

33.79

Application: Evoque and Freelander 2.

Description: Installer for bellhousing differential oil seal. Use with 307-520.

Approximate dimensions: Overall diameter 80mm(3.15"), inside diameter 54mm(2.13"), height 48.5mm(1.9").

find out more

Installer Oilseal

Installer Oilseal

155.89

Application: Evoque and Freelander 2.

Description: Installer for quillshaft oil seal. Use with 307-520.

Approximate dimensions: Overall diameter 80mm(3.15"), height 64mm(2.52").


find out more

Pinion Bearing for Salisbury Differential

Pinion Bearing for Salisbury Differential

12.37

Application: Series 3 Long Wheel Base and Defender 110 models with rear Salisbury axle.

Descrtiption: Timken/Japanese sourced outer pinion taper roller bearing for Salisbury differentials.

Approximate dimensions: Outside diameter 2.85"(72.3mm), inside diameter 1 3/8"(34.9mm), depth 26.7mm(1.05")

Bearing numbers: HM88649/ HM88610

find out more
